| Processor | 14th Gen Intel Core i3 through Core i9, up to 125W K-class |
| Operating System | Windows 11 or Ubuntu Linux 22.05 LTS |
| Memory | 4x DDR5 DIMM slots, 128GB max. |
| Storage | 3x M.2 2280 slots and 3x 3.5-inch drives Front-accessible 3.5-inch drive available with specific configurations |
| Graphics | - Intel® UHD Graphics 730 supported for 14th Gen Intel® Core™ i3-14100 processor
- Intel® UHD Graphics 770 supported for remaining processors
- NVIDIA® RTX™ 6000 Ada Generation, 48 GB GDDR6
- NVIDIA® RTX™ 5000 Ada Generation, 32 GB GDDR6
- NVIDIA® RTX™ 4500 Ada Generation, 24 GB GDDR6
- NVIDIA® RTX™ 4000 Ada Generation, 20 GB GDDR6
- NVIDIA® RTX™ 2000 Ada Generation, 16GB GDDR6
- NVIDIA® T1000, 8 GB GDDR6
- NVIDIA® T1000, 4 GB GDDR6
- NVIDIA® T400, 4 GB GDDR6
- AMD Radeon™ Pro W7900, 48 GB GDDR6
- AMD Radeon™ Pro W7600, 8 GB GDDR6
- AMD Radeon™ Pro W7500, 8 GB GDDR6
- AMD Radeon™ Pro W6400, 4 GB GDDR6
- AMD Radeon™ Pro W6300, 2 GB GDDR6
|
| Ports | Front:
- USB 3.2 Gen 1 (5 Gbps) port
- USB 3.2 Gen 1 (5 Gbps) port with PowerShare
- USB 3.2 Gen 2 (10 Gbps) Type-C® port
- USB 3.2 Gen 2×2 (20 Gbps) Type-C® port with PowerShare
- Universal Audio port
Rear: - (2) DisplayPort 1.4a HBR2 ports
- (2) USB 2.0 (480 Mbps) ports with SmartPower
- RJ45 (1 GbE) Ethernet port
- (2) USB 3.2 Gen 2 (10 Gbps) ports
- (2) USB 3.2 Gen 2 (10 Gbps) Type-C® ports
- Audio line-out
- Optional Port (VGA, HDMI 2.0, DP++ 1.4a H
|
| Slots | Front:
Rear: - Full-height Gen5 PCIe x16 slot
- Full-height Gen3 PCIe x4 slot
- Full-height Gen4 PCIe x4 open-ended slot
|
| Dimensions | - Height: 14.68 in. (372.90 mm)
- Width: 6.81 in. (173.00 mm)
- Depth: 16.54 in. (420.20 mm)
- Weight (minimum): 16.71 lb (7.58kg)
- Weight (maximum): 35.38 lb (16.05 kg)
|
| Wireless | - Qualcomm® Wi-Fi 6E WCN6856-DBS, 2×2, 802.11ax, MU-MIMO, Bluetooth® 5.3 wireless card
- Intel® Wi-Fi 6E AX211, 2×2, 802.11ax, MU-MIMO, Bluetooth® 5.3 wireless card
|
| Power | - 300W Platinum internal power supply unit (80PLUS Platinum Certified)
- 500W Platinum internal power supply unit (80PLUS Platinum Certified)
- 1000W Platinum internal power supply unit (80PLUS Platinum Certified)
|
| Hardware Security | - Security-cable slot
- Padlock loop
- Lockable Cable Cover (optional)
- Lockable Bezel and Key for Front Accessible SATA HDD (optional)
- Chassis intrusion switch
- Trusted Platform Module TPM 2.0
- Intel Integrated TPM
|
